The Logi Valve Brass Swivel Nut Ball Valve Male x Female BSP Lead Free Gas Approved is designed for gas isolation and control in residential, commercial and industrial installations. Certified to AS 4617 and AGA approved, it provides a compliant solution for Australian gas systems where reliability and safety are essential.
The valve features a full-bore design that supports efficient gas flow through the pipeline, while the swivel nut connection assists with installation and alignment. A blow-proof spindle and aluminium handle provide dependable operation and ease of use in demanding service environments.
Constructed from brass with a stainless steel ball, PTFE seals and HNBR O-rings, the valve is rated for operating temperatures from -20ºC to 120ºC and pressures up to 2100kPa. Each valve is 100% pressure tested to ensure consistent performance and quality.
Commonly searched under Austworld LOGI product code SN15MG and SN20MG, this gas-approved ball valve is available in 15mm and 20mm sizes to suit a wide range of gas installation requirements.
Features
- Male x female BSP threaded connections.
- Swivel nut connection design.
- AGA approved.
- Certified to AS 4617.
- Full-bore design.
- Blow-proof spindle.
- 100% pressure tested.
- Brass body and cap.
- Stainless steel ball.
- PTFE seals.
- HNBR O-rings.
- Aluminium handle.
- Working temperature -20ºC to 120ºC.
- Maximum pressure rating 2100kPa.
- Available in 15mm (½″) and 20mm (¾″) sizes.
