The Logi Valve Brass Swivel Nut Ball Valve Flared Compression x Female BSP Lead-Free Gas-Approved is designed for gas isolation applications that require reliable performance and compliance with Australian standards. Manufactured from quality brass with stainless steel internal components, the valve is tested and certified to AS 4617 for use in approved gas installations.
The full-bore design allows efficient gas flow, while the swivel nut connection assists with installation and alignment. A blow-proof spindle and durable aluminium butterfly handle provide dependable operation in residential, commercial, and industrial gas systems.
Rated for operating temperatures from -20ºC to 120ºC and a maximum pressure of 2100kPa, this valve is built for demanding service conditions. PTFE seals and HNBR O-rings contribute to long service life and reliable sealing performance.
Commonly searched under Austworld LOGI product SKU H20G2015, this gas-approved ball valve provides a compliant solution for gas control and isolation applications throughout Australia.
Features
- DN15 x 20mm (¾″) size configuration.
- Flared compression x female BSP connection.
- AGA approved.
- Certified to AS 4617.
- Full-bore design.
- Swivel nut connection.
- Blow-proof spindle.
- Aluminium butterfly handle.
- 100% pressure tested.
- Brass body and cap.
- Stainless steel ball and spindle.
- PTFE seals.
- HNBR O-rings.
- Working temperature -20ºC to 120ºC.
- Maximum pressure rating 2100kPa.
