The Logi Valve Brass Swivel Nut Ball Valve Male x Female BSP Lead Free Watermarked is designed for isolation and flow control in potable water installations. Manufactured from DR lead-free brass and certified to WMTS 012, it is suitable for residential, commercial and plumbing applications requiring compliance with Australian standards.
Featuring a swivel nut connection and full-bore design, the valve provides straightforward installation while maintaining unrestricted flow through the valve body. The blowproof spindle construction and 100% pressure-tested design support reliable long-term operation in demanding water service environments.
Available in 15mm and 20mm sizes, the valve is rated to a maximum working pressure of 2500kPa and operating temperatures from 1ºC to 95ºC. Stainless steel internal components, PTFE seals and FKM O-rings contribute to durability and performance across a wide range of potable water applications.
Commonly searched under Austworld LOGI product SKUs SN15MWLF and SN20MWLF, this WaterMark-approved valve provides a compliant lead-free solution for Australian plumbing systems. Austworld Logi product codes SN15MWLF and SN20MWLF.
Features
- DR lead-free brass body and cap.
- Male x female BSP threaded connections.
- Swivel nut connection design.
- Full-bore flow path.
- WaterMark approved.
- Tested and certified to WMTS 012.
- Blow-proof spindle.
- 100% pressure tested.
- Working temperature 1ºC to 95ºC.
- Maximum pressure rating 2500kPa.
- Stainless steel ball and retaining ring.
- PTFE seals and FKM O-rings.
- Available in 15mm and 20mm sizes.
